748.8V 173AH Lithium Ion Battery

Weight	1985 lbs
Brand	Lithium Battery Company

SKU LBC748.8173 Category 96V + Lithium Batteries

LBC748.8173 Lithium Battery Pack

The LBC748.8173 is a high-performance lithium battery pack designed for applications requiring reliable and efficient energy storage. With a nominal voltage of 748.8V and a capacity of 173Ah, this pack offers a robust solution for various industrial and commercial uses.

Specification	Details
Nominal Voltage	748.8 V
Nominal Capacity	173 Ah
Standard Charging Current	86.5 A
Max. charge current	173 A
Standard Discharging Current	86.5 A
Max. Discharge Current	173 A (peak 346A 10S)
Working voltage range	585 ~ 854 V
Standard Charging Method	CCCV
Overcharge Protection Threshold	3.68 V/cell
Over Discharge Protection Voltage Threshold	2.50 V/cell
Over Discharge Current Protection	About 600 A
Balance Start Voltage/Balance Current	3.40 V/30 mA
Short Circuit Current Protection Function	OK
Over Temperature Protection Threshold	Discharge 60 ± 5℃
Communication protocol	CAN / RS485 (Plug DJ7021-1.5-21)
Cycle Life	3000 cycles 80%
Product Size	L2000 * D700 * H520 mm
PACK assembly way	STELL
Charge Type of output	SB50 AWG8 L=800mm
Discharge Type of output	M8 AWG6 L=800mm
Type of output wire	RVV 2*1.5
Output wire length	900 mm
Product Weight	About 1100 Kg
Charging Temperature	0 ~ 45℃
Discharging Temperature	-20 ~ 55℃
Storage Temperature	1 month: -10℃ ~ 50℃ 3 months: 0℃ ~ 30℃ One year: 20℃ ~ 25℃
Relative Humidity for Storage	5% ~ 95% RH
Cell Certification	UL1642 / UL1973
Quality Assurance Period	2 years

Key Features

High-Performance LFP Cells: Ensuring superior safety, long cycle life, and high energy density.
Robust Protection Features: Protects against overcharge, over-discharge, over-discharge current, and short-circuit.
Wide Operating Temperature Range: Suitable for use in various environmental conditions.
Reliable Energy Storage: With a cycle life of 3000 cycles at 80% capacity retention.
Quality Assurance: 2-year quality assurance period for peace of mind.

Applications

Electric Vehicles: Powering electric cars, buses, and other transportation with high energy demands.
Energy Storage Systems: For renewable energy storage solutions, such as solar and wind power.
Industrial Equipment: Providing reliable power for heavy machinery and industrial applications.
Telecommunications: Backup power for telecom towers and data centers.
Marine Applications: Powering electric boats and yachts.
UPS Systems: Uninterruptible power supply for critical infrastructure.
