12V 201AH Lithium Ion Battery

Weight	63 lbs
Brand	Lithium Battery Company

SKU LBC12201.6 Category 12V Lithium Batteries

LBC 12.8V 201.6AH – LFP Battery Pack

The LBC 12.8V 201.6AH – LFP Battery Pack is a high-performance battery solution designed for applications requiring reliable and efficient energy storage. With its advanced LFP chemistry, this battery pack offers superior safety, long cycle life, and excellent low-temperature performance.

Specification	Details
Nominal Voltage	12.8 V
Nominal Capacity	201.6 Ah
Standard Charging Current	40 A
Max. Charge Current	100 A
Standard Discharging Current	40 A
Max. Discharge Current	200 A
Working Voltage Range	10 ~ 14.6 V
Standard Charging Method	CCCV
Overcharge Protection Threshold	3.75 V/cell
Over Discharge Protection Voltage Threshold	2.50 V/cell
Over Discharge Current Protection	About 220 A
Balance Start Voltage/Balance Current	3.60 V/25 mA
Short Circuit Current Protection Function	OK
Over Temperature Protection Threshold	1
Communication protocol	CAN / RS485 / Wifi / Bluetooth
Cycle Life	2000 cycles 80%
Product Size	L301/W200/D283 ±2 mm
PACK assembly way	Metal Case
Charge Type of output	250 A
Discharge Type of output	250 A
Type of output wire	1
Output wire length	1
Product Weight	About 28.5 kg
Charging Temperature	-30 ~ 45℃
Discharging Temperature	-50 ~ 60℃
Storage Temperature	1 month: -10℃ ~ 50℃ 3 months: 0℃ ~ 30℃ One year: 0℃ ~ 25℃
Relative Humidity for Storage	5% ~ 95% RH
Cell Certification	UL1642/UL1973
Quality Assurance Period	3 years

Key Features

High Capacity: With a nominal capacity of 201.6Ah, this battery pack provides substantial energy storage.
Robust Protection: Features overcharge, over-discharge, over-discharge current, and short-circuit protection.
Wide Operating Temperature Range: Suitable for use in various environments, from -50°C to 60°C.
Long Cycle Life: Offers up to 2000 cycles with 80% capacity retention.
Safety Certifications: Complies with UL1642 and UL1973 safety standards.
Customizable Design: Available in various sizes and configurations to meet specific application needs.

Applications

Electric Vehicles: Ideal for powering electric bikes, scooters, and other light electric vehicles.
Energy Storage Systems: Suitable for renewable energy storage solutions, such as solar and wind power systems.
Industrial Equipment: Can be used in a variety of industrial applications requiring reliable and efficient power.
Backup Power: Provides emergency power for critical systems and devices.
Telecommunications: Used in base stations and other telecom equipment for uninterrupted power supply.
Marine Applications: Power source for marine equipment and electric boats.
