High-Performance 84V 15A Lithium Ion Charger

Description



Upgrade your electric applications with the 84V 15A Lithium-Ion Charger, tailored for devices requiring high voltage and current input. This lithium ion charger promises a quick and secure charging experience, delivering an impressive output of up to 84V and 15A. Ensure an optimal and efficient charge for any lithium-ion battery, leveraging the robust capabilities of this 15A lithium-ion charger.



PRODUCT SPECIFICATION

Model: AP-PF1200CH08400150

General Information

ModelAP-PF1200CH08400150

Overview

The model AP-PF1200CH08400150 charger uses an 80 * 80 * 20mm bearing fan-cooled charger. The input voltage range is 100~240Vac, the single-channel voltage is up to 84V, and the maximum current is 15A. The power supply has reverse polarity protection. The entire power supply is designed in strict accordance with safety regulations.

Electrical Specification

No. Item Technical Specification Remark
1
2 Max output voltage 84V± 0.2V
3 Output current 15A
4 Input voltage 100~240 Vac

Environmental Conditions

No. Item Technical Index Unit Remark
1 Operating temperature -10~+45°C   Full load
2 Storage temperature -40~70°C
3 Relative humidity 5%~95%   Non-condensing
4 Altitude ≤2000m   Normal operation
5 Cooling method 80x80x25mm Bearing fan

The Lithium Battery Company Intl.
4912 W Knox Street | Suite 100 Tampa, FL 33634 | (844) 438-5484
Lithiumbatterycompany.com

Additional information

Weight 10 lbs
